Off-road Caravans with Independence and Comfort to go anywhere
COMPACT OFF-ROAD CARAVANS
From $87,420 ex Ballina. Made in Ballina, Australia
Click on the image above for the list of eBooks that cover these points by topic |
||
|---|---|---|
Model eBook  |
||
Standard in every 2018 model: Lithium Batteries, all super-light Black Optima Solar arrays with new smart controllers, and the Smart Touch Plus. This system only reads information and is NOT a remote control system. We still use traditional switches. Most models have Smart refrigeration and all are equipped for the automated waterless toilet if you choose this option.
Lithium Batteries on EVERY KIMBERLEY MODEL.
- 200Ahr Lithium Battery in every model
- 600Ahr available for Kruiser S, T Class
- Bluetooth connected for monitoring and event records
- Charges at twice the speed of conventional AGM or Lead crystal batteries
- Great weight reduction.
- Long cycle life
SMART TOUCH PLUS on EVERY KIMBERLEY MODEL.
- NEW Gorilla Glass high definition display in every model
- Batteries, water tank levels on all models.
- Solar, Inverter, Fridge and Freezer temp and power on selected models
- Smartphone bluetooth connected for every model.
- With Kimberley SmartRV on Wifi*, there is remote service access to your system from anywhere in the world. Security feature prevents spamming.
Smartphone app for every model: easy to follow second screen:
- for battery, water levels, grey water, solar system, refrigeration.
- Bluetooth connection : no internet needed.
- "Future proof" with planned CI-Bus compatibility to Dometic, Truma, and Alko products. This should enable remote control of air-conditioning and heating from your smartphone. (CI-Bus is Caravan Industry Bus which Kimberley is committed to)
- 80 uses, no smell, no need for dump station.
- Available in every model and equipped with:
- a booster fan,
- a 12V heater
- and a removable liner.
STABILITY IN TOWING
With lighter vehicles and improved vehicle braking, there is a greater need for more efficient braking in caravans. Simply put: if the vehicle is lighter and brakes faster and stronger than the caravan, the caravan inertia will push to a jack knife scenario. The solution is to have stronger and more powerful brakes in the caravan that act as a "parachute" behind the vehicle.
Kimberley have released the most powerful disc braking ever with Lightweight ventilated disc braking and dynamic Kimberley callipers.
As a comparison these are significantly more powerful than the Alko disc system because of a higher controlled hydraulic pressure.
- Using Lithium and Superlight solar achieves Weight reduction of: 60kgs -120kgs : easier to tow, longer range
- Matching Wheels and Tyres for European 120mm PCD standard:
- Match Landrover Discovery 3, 4 & 5 , Range Rover, Touareg, Amarok.
The Kimberley Karavan, a lightweight folding off road caravan that can go anywhere. Kimberley Karavans are unique with their internal shower and toilet, comfortable internal seating and luxury finishes. There is 2.2m of head clearance. Yet they are no wider than a 4WD so can travel absolutely anywhere!
The Kimberley Karavan It is designed to be BOTH self contained and "off-road". One feature that makes this Australian off-road caravan unique is the design of the low drag fibreglass sides and roof with such a low travelling profile. The benefit of this fuel saving is not the saving in fuel cost, but the ADDED RANGE from the standard tanks in regular 4WDs. This ADDED RANGE is so important for you to "go anywhere"!
Kimberley Karavans have a 5 Year Warranty on the Chassis and Suspension Arms... and this warranty transfers to second buyers in the 5 years! Service and customer support is equally important. Kimberley has a Dealer network in 6 States Australia wide, a service network extending to remote areas and a dedicated support staff in Ballina NSW.
Great Australian designs result in both the lightest AND the most compact off-road caravan
that is NOT a vinyl sided pop top for storage!
All Using Split Air-conditioning |
Travel Height 31.5inch Tyres |
Garage Height 31.5inch Tyres |
Best Garage Height With ParkingWheels |
|---|---|---|---|
| Model with Coil Springs | 2190 mm | 2170 mm | 2120 mm |
| Model with Air Suspension | 2100 mm | 2080 mm | 1980 mm |
| Model with Air Suspension and Automatic Satellite on roof |
2231 mm | 2211 mm | 2111 mm |
Choice of compact folding or full size off-road caravan
The photo below is the internal view of the new 18ft S Class Kruiser which is an alternative to the Kimberley Karavan
Self Contained Features
Self-Contained feature |
Kimberley Karavan Range |
Solar Energy to provide independent sustainable power without generator |
Yes |
AGM Battery Capacity for independent use |
Yes |
Super light high capacity Lithium Ion Battery with extended independent use |
Yes |
Fuel Cell backup when insufficient solar available |
Yes |
12V Refrigerator with enhanced remote compressor> high performance with low energy |
Yes |
Diesel* Ceramic cooktop inside |
Yes |
Diesel* Hot Water |
Yes |
Hot water recovery space* heater |
Yes |
Diesel* Air Heater |
Yes |
12V Membrane heater |
Yes |
12V operated Hi-power** Air-conditioner |
Yes |
240V air-conditioner needs generator |
Yes |
Hybrid Power of Lithium Batteries and much smaller portable generator |
Yes |
Fibreglass construction with added insulation for enhanced thermal insulation properties |
Yes |
Dual Water Tanks (one for uncertain water) |
Yes |
Pump from billabong bypassing tanks |
Yes |
Grey Water Tank |
Yes |
Black Water tank for Toilet |
Yes |
Waterless eco Toilet |
Yes |
Hi-power Data Antennae |
Yes |
Energy Management System |
Yes |
Water Management System |
Yes |
30 litre durable rubbish storage container |
Yes |
* Diesel is more self-contained as common fuel to vehicle and: 1. The consumption is low, a 12L tank lasts 3 months+ 2. it can be bio-diesel or a combination of the two 3. It is available everywhere ** Lite: Has limited cooling output. Hi-power: has 2.2kw+ output, operation not continuous Hybrid: needs only 1kVA small generator for 2.2kW air-conditioner.
Off-road Features
Off-road feature |
Kimberley Karavan Range |
Same width as most 4WD vehicles |
Yes |
Similar or lesser height as most 4WD vehicles |
Yes |
Hot dipped galvanized flexible laser-locked chassis with 5 year transferrable warranty |
Yes |
Independent trailing arms giving high clearance |
Yes |
Coil Springs with override straps (no leaf springs) |
Classic Only |
Air-suspension with wide range adjustable height |
Yes |
“Limp home” Integrated compression stops for air-bags |
Yes |
Anti-sway Bar for stability with low air pressure |
Yes |
Mono-tube high capacity shock absorbers |
Yes |
Rear recovery points capable of 6,000kg recovery |
Yes |
Front angled deflector and stone deflecta™ shield under unit |
Yes |
Extended Drawbar for revolutionary reverse turn |
Yes |
Fibreglass low-drag co-efficient for significantly reduced fuel consumption |
Yes |
Use of extra-fine Midge-proof screens on all windows and doors |
Yes |
Use of powered extraction vents for enhanced airflow |
Yes |
Integrated outside kitchen> hot/cold water & sink |
Yes |
Access Toilet easily for roadside stop |
Yes |
360 degree rotatable and rubber dampened hitch |
Yes |
Water resistant (water proof with right operation) to 1.2m for water crossings |
Yes |
Dust resistant (dust proof with right operation) |
Yes |
NO timber floor or used in any construction |
Yes |
One piece internal liner/ floor in cast poly-ethylene |
Yes |
Vibration resistance chrome over brass spring catches throughout (no plastic) |
Yes |
Stainless steel on external finishes used for table |
Yes |
Matching wheels and tyres for most vehicles |
Yes |
Capable of up to 35 inch tyres with spares under |
Yes |
